| 货号 | 包装规格 | 操作 |
|---|---|---|
| 990445-1EA | 1 each |
Our lithium manganese iron phosphate (LMFP) electrode sheet is a ready-to-use cathode designed for lithium-ion battery research. The LMFP cathode film is 80 µm thick, single-sided, and applied to a 16 µm thick aluminum foil current collector measuring 5 × 10 inches (127 mm × 254 mm). The composition consists of 88% lithium iron phosphate (LFP), 4% Poly(vinylidene fluoride) [PVDF], and 8% carbon black. The active material, olivine LiMnxFe1−xPO4, is a well-studied cathode material known for its excellent cycling stability.
Lithium Manganese Iron Phosphate is a sustainable cathode material combining manganese and iron for improved safety, cost-effectiveness, and environmental friendliness. Its use in lithium-ion batteries supports greener technologies by enhancing energy efficiency, extending battery life, and reducing reliance on scarce or toxic materials. Click here for more information.
我们的磷酸锰铁锂（LMFP）电极作为锂离子电池研究的正极。它具有成本效益，环保，无钴。与磷酸铁锂（LFP）相比，LMFP具有更高的标称电压，能量密度高出近20%（LMFP为3.8 V，LFP为3.2 V）。此外，LMFP提供高比容量与大多数其他锂离子化学品相比，LMFP电池具有更低的容量损失率和更长的电池寿命。由于其低成本、低毒性、稳定性和可靠的性能，基于LMFP的电池越来越多地应用于车辆和备用电源应用中。
| 英文名称 | Lithium manganese iron phosphate (LMFP) |
| 线性分子式 | LiMn（x）Fe（x-1）PO4</p> |
| NACRES | NA.21 |
| UNSPSC | 12352302 |
| InChI key | ZWXLZABZHZXDGX-UHFFFAOYSA-K |
| SMILES字符串 | [Li].[Mn].[Fe].O=P([O-])([O-])[O-] |
| 等级 | 电池级 |
| 描述 | 3.8V vs. Li/Li + |
| 形态 | 片 |
| 成分 | 活性材料负载8.9 mg/cm 2 ± 5%，≥85%（重量）（不包括集电器） |
| 质量等级 | 100 |
| 绿色替代产品特性 | 节能设计 了解绿色化学原理。 |
| 可持续性 | 更环保的替代产品 |
| 胶片尺寸 | 80 μm × 16 μm，铝集流体 |
| 颗粒大小 | 2 μm（活性物质特性） |
| 容量 | （面积容量1.25 mAh/cm 2）;（首次放电容量≥140 mAh/g） |
| 应用 | 电池制造 |
| 更环保的替代类别 | 促成性 |
| 包装规格（货号 990445-1EA） | 1 each |
